Beyond all odds



DAC-EV33  and Ev33

DAC or CD/SACD player analogue EXTERNAL MODULE for analog audition

where analogue and digital at last meet together







Hit Counter

dal 20-4-2008





comments





DAC+Ev33

INPUT USB , SPD/If coax and optical or I2S- Analogue stage as Ev33

Ev33

 Ev33  is an EXTERNAL ANALOGUE MODULE  to be connected directly to the DAC CHIP output. See detail for application





DAC+Ev33









 comparison toward a 3 chassis 50,000 euros player, maybe you kow it





the faces are of course full of laughing especially when the other 15,000 euros player got its chance to let his voice out.

The next one is owned by one of these 2  guys. He took it of course as joke spending so much money for nothing and this is the best way to face the reality, else he would normaly hang itself



ofaces completely restored and relaxed  when the DAC-EV33 has revealed the truth





Two solutions for the Ev33 , each one need to connect the Ev33 internally to the DAC or the CD player, completely eliminating operational amplifiers, discrete or tube in the  internal analogue output section.

While the DAC+Ev33  has on its own an internal 24/192 DAC with a 120 dB s/n made only by transformers

Ev33 it can be connected to any pure PCM current output DAC CONVERTER  (starting from 1 mA output),



ACTIVE VOLTAGE AMPLIFIERS: NONE

  • 2 step-up trasformers per channel - each one driven in CURRENT MODE (NOT Current generators). The 2 Single ENDED transistors are UNable to control the current thru the low input impedance of the transformers (36 ohms), so avoiding current local Feed Back.  The S.E. transistors are fed by means of 8 INDUCTIVE pi-grec cells. The signal transformers used are the new Royal Device RD 15 -4

  • internal power supply with 8 inductive pi-grec cells and 6 resistive cells separated for each channel, bias and output stages

  • coupling via transformers and one or 2 emitter follower S.E. transistor stage used as impedance adaptor for extreme low noise and negligible THD and intermodulation distortion without the use of any Feed back.

  • minimum input current: 1 mA

  • Input impedance: 300 ohm - need 30 ohm external load into the DAC output section

  • Frequency response:  12 a 80 KHz (-1 dB)

  • Maximum output voltage:  5 Vrms - standar setting 2,5 Vrms

  • minimum load > 700 ohm- Standard external load 10 Kohm with 3 Kohm internal load

  • S/N > 95 dB

  • 6,5 mm chassis

  • metalized racing blu finishing - front and back mirror finishing stainless steel



INTERNAL Ev33 BLOCK DIAGRAM









Ev33 frequency response:  +2 dB @ 15 Hz / -1,2 dB @ 80 KHz



10 KHz square wave response: 4,4 microseconds







 Ev33  before assembling into the the final BLUE metalized chassis



the Ev33 connected to the CD 85 player in the ROYAL DEVICE audio room

(internal TDA 1541 A S1 power supplies  fed by 3 inductive pi-grec cells )



where analogue and digital at last meet together



HERE FOLLOWS some of the modified CD or SACD or DVD players



In thi section we had the possibility to compare 4 players all, umodificed with its own external Royal Device EV3 module

A Phlips 960 on the left, a ONKYO INTEGRA on the center a ROTLA with PCM 63 on the right. till there is the CD 85 MArantz of the Royal Device audio room on the back

The players where suing their own UDIN CD syncronized together. by means of a switch placed on the listening position, it is possible to swithc from one to the other.









ONKYO GRAND INTEGRA DX-G10



ROTEL dotato di convertitori PCM 63 (PCM a 20 Bit)





 Philips 960 on the left  connected to the EV3 and the ionternal view with inductive power supplies on the DAC and antijittering clock..







DENON DVD 2930  with internal  Burr Bown PCM 1791 DACs

back view of the interconnections with the external EV3.



Here an External DAC using the  24/192 CS4396 chip







 another External DAC using the Burr Brown PCM 63





CALIFORNIA AUDIO LABS SIGMA using CS 4328. All the internal tube and filtering with the uA 741 operational amplifier  has been completely overpass.







ONKYO DVSP 503E  on the right using Burr Bown PCM 1742 and a MARANTZ CD 85 on the left
